DAIKIN FBA125B-VFY 12.5kW Premium Inverter Slim-Line Ducted System | 3 Phase
DAIKIN FBA125B-VFY 12.5kW Premium Inverter Slim-Line Ducted System | 3 Phase
Regular price
$5,685.00 AUD
Regular price
Sale price
$5,685.00 AUD
Unit price
per
Couldn't load pickup availability
FREE PICKUP ACROSS AUSTRALIA! Contact us now for details
DAIKIN FBA125B-VFY 12.5kW Premium Inverter Slim-Line Ducted System | 3 Phase
Indoor Unit : FBA125BVMA
Outdoor Unit : RZAV125CY1
Available Controllers:
Included:
BRC1E63 – Standard Nav Ease Controller
Optional:
BRC230Z4B9 – Up to 4 Zones (230-240v)
BRC230Z8B9 – Up to 8 Zones (230-240v)
BRC24Z4B9 – Up to 4 Zones (24v)
BRC24Z8B9 – Up to 8 Zones (24v)
12.5 kW Cooling
14.0 kW Heating
Specifications:
| Indoor Unit | FBA125BVMA | |
| Outdoor Unit | RZAV125CY1 | |
| Rated Capacity | Cool (kW) | 12.5 |
| Heat (kW) | 14.0 | |
| Capacity Range | Cool (kW) | 5.0-14.0 |
| Heat (kW) | 5.1-16.0 | |
| Power Input (Rated) | Cool (kW) | 3.68 |
| Heat (kW) | 3.72 | |
| E.E.R./C.O.P. | Cool/Heat | 3.40/3.76 |
| Air Flow Rate (Rated) | I/S | 600 / 508 / 417 |
| Indoor Sound Level (@1.5m) | dBA | 68 |
| Dimensions (HxWxD) | Indoor (mm) | 245 x 1400 x 800 |
| Outdoor (mm) | 1430 x 940 x 320 | |
| Weight | Indoor(kg) | 47 |
| Outdoor(kg) | 93 | |
| Power Supply | V/Hz | 3 Phase, 380-415V, 50Hz |
| Compressor Type | Hermetically Sealed Swing Type | |
| Refrigerant | R32 | |
| Pipe Sizes | Liquid (mm) | 9.5 (Flared) |
| Gas (mm) | 15.9 (Flared) | |
| Drain (mm) | ID 25 / OD 32 | |
| Outdoor Operating Range | Cool (°CDB) | – 5 to 50 |
| Heat (°CWB) | – 15 to 15.5 | |
| EPA Sound Power Level | dBA | – |
| Outdoor Sound Level @1m | Pressure dBA (C/H) | 52/54 |
