DAIKIN FDYAN71A-CV 7.1kW Inverter Ducted Air Conditioner System | 1 Phase
DAIKIN FDYAN71A-CV 7.1kW Inverter Ducted Air Conditioner System | 1 Phase
Regular price
$3,735.00 AUD
Regular price
Sale price
$3,735.00 AUD
Unit price
per
Couldn't load pickup availability
FREE PICKUP ACROSS AUSTRALIA! Contact us now for details
DAIKIN FDYAN71A-CV 7.1 kW Inverter Ducted Air Conditioner System | 1 Phase
Indoor : FDYAN71AV1
Outdoor: RZA71CV1
Available Controllers:
Included:
BRC1E63 – Standard Nav Ease Controller
Optional:
BRC230Z4B9 – Up to 4 Zones (230-240v)
BRC230Z8B9 – Up to 8 Zones (230-240v)
BRC24Z4B9 – Up to 4 Zones (24v)
BRC24Z8B9 – Up to 8 Zones (24v)
7.1kW Cooling
7.5kW Heating
Specifications:
| INDOOR UNIT | FDYAN71AV1 | ||||||
| OUTDOOR UNIT | RZA71CV1 | ||||||
| Rated Capacity | Cool (kW) | 7.1 | |||||
| Heat (kW) | 7.5 | ||||||
| Capacity Range | Cool (kW) | 1.8-8.0 | |||||
| Heat (kW) | 2.0-9.0 | ||||||
| Power Input (Rated) | Cool (kW) | 2.20 | |||||
| Heat (kW) | 1.93 | ||||||
| E.E.R/C.O.P | C/H | 3.23/3.89 | |||||
| TCSPF (Residential) | Hot/Average/ Cold | 4.43/3.88/3.94 | |||||
| HSPF (Residential) | Hot/Average/ Cold | 4.17/3.85/3.41 | |||||
| Airflow Rate (Nominal/Max) | l/s | 425/566 | |||||
| Indoor Sound Level (H) @ 1.5m | dBA (C/H) | 37.3/40.5 | |||||
| Piping Length | m | 50 | |||||
| Indoor Fan Speeds | H/M/L | ||||||
| Dimensions (HxWxD) | Indoor (mm) | 300x1210x900 | |||||
| Outdoor (mm) | 595x845x300 | ||||||
| Weight | Indoor (kg) | 40 | |||||
| Outdoor (kg) | 45 | ||||||
| Power Supply | V/Hz | 1 Phase, 220-240V, 50Hz | |||||
| Compressor Type | Hermetically Sealed Swing Type | ||||||
| Refrigerant | R32 | ||||||
| Pipe Sizes | Liquid (mm) | 6.4 (Flare) | 9.5 (Flare) | ||||
| Gas (mm) | 12.7 (Flare) | 15.9 (Flare) | |||||
| Drain (mm) | ID 25 / OD 32 | ||||||
| Supply Air Opening | mm (HxW, Flange) | 185×852 | |||||
| Return Air Opening | mm | 1×400 (Oval) | |||||
| Outdoor Operating Range | Cool (°CDB) | -5 to 46 | |||||
| Heat (°CWB) | -15 to 16 | ||||||
| EPA Sound Power Level | dBA | 68 | |||||
| Outdoor Sound Level (H) @ 1m | Pressure dBA (C/H) | 48/51 | |||||
