DAIKIN SKY AIR FTXC100-AV 10.0kW Reverse Cycle Split System Air Conditioner | 1 Phase
DAIKIN SKY AIR FTXC100-AV 10.0kW Reverse Cycle Split System Air Conditioner | 1 Phase
Regular price
$4,045.00 AUD
Regular price
Sale price
$4,045.00 AUD
Unit price
per
Couldn't load pickup availability
FREE PICKUP ACROSS AUSTRALIA! Contact us now for details
10.0 kW Cooling
11.2 kW Heating
DAIKIN SKY AIR FTXC100-AV 10.0kW Reverse Cycle Split System Air Conditioner | 1 Phase
Specifications:
|
Model Name |
Indoor unit | FTXC100AV1A | ||
| Outdoor unit | RXC100AV1A | |||
| Power supply | 1 Phase, 220-240V, 50Hz | |||
| Cooling capacity1,3 Rated (Min. – Max.) |
kW |
10.0
(5.0-11.2) |
||
| Heating capacity2,3 Rated (Min. – Max.) |
kW |
11.2
(5.1-12.5) |
||
| Power consumption | Cooling1 | kW | 3.11 | |
| Heating2 | kW | 3.48 | ||
| EER | Cooling | kW/kW | 3.22 | |
| COP | Heating | kW/kW | 3.22 | |
| AEER | Cooling | 3.17 | ||
| ACOP | Heating | 3.17 | ||
| TCSPF (Cooling) Commercial / Residential | Hot | 5.03 / 4.63 | ||
| Average | 5.13 / 4.18 | |||
| Cold | 5.49 / 4.33 | |||
| HSPF (Heating) Commercial / Residential | Hot | 4.66 / 4.64 | ||
| Average | 4.25 / 3.95 | |||
| Cold | 3.77 / 3.42 | |||
| Indoor unit | Colour | Fresh white | ||
| Airflow rate (H / M / L) | /s | 433 / 383 / 317 | ||
| m3/min | 26.0 / 23.0 / 19.0 | |||
| Sound pressure level4 (H / M / L) | dB(A) | 49.0 / 45.0 / 41.0 | ||
| Sound power level (H / M / L) | dB(A) | 65 / 62 / 58 | ||
| Dimensions (HXWXD) | mm | 340X1,200X240 | ||
| Machine weight | kg | 17 | ||
| Certified operation range | Cooling | °CWB | 14 to 25 | |
| Heating | °CDB | 15 to 27 | ||
| Outdoor | Colour | Ivory White | ||
| unit | Compressor | Type | Hermetically sealed swing type | |
| Motor output | kW | 3.3 | ||
| Refrigerant charge (R-32) |
kg |
3.75
(Charged for 30 m) |
||
| Sound pressure level 4 | Cooling / Heating | dB(A) | 51 / 53 | |
| Night quiet mode | dB(A) | 47 | ||
| Sound power level | dB(A) | 70 | ||
| Dimensions (HXWXD) | mm | 1,430X940X320 | ||
| Machine weight | kg | 93 | ||
| Certified operation range | Cooling | °CDB | -5 to 50 | |
| Heating | °CWB | -15 to 15.5 | ||
| Piping connections | Liquid (Flare) | mm | o/ 9.5 | |
| Gas (Flare) | mm | o/ 15.9 | ||
| Drain | Indoor unit | mm | VP13 (I.D.o/ 13XO.D. o/ 18) | |
| Outdoor unit | mm | o/ 26.0 (Hole) | ||
| Max. interunit piping length | m | 75 (Equivalent length 90) | ||
| Max. installation height difference | m | 30 | ||
| Heat insulation | Both liquid and gas piping | |||
