Indoor : MSZ-EF50VGS-A1
Outdoor : MUZ-EF50VG-A1
System : MSZEF50VGSKIT
Mitsubishi Electric MSZEF50VGSKIT 4.8kW EF Series Split System | Silver
Specifications:
| MSZ-EF Series (Wall Mounted) | ||||
| Indoor Unit | MSZ-EF50VG (W/B/S) -A1 | |||
| Outdoor Unit | MUZ-EF50VG-A1 | |||
| Refrigerant | R32 | |||
|
Cooling |
Capacity [Rated] | kW | 5.00 | |
| Capacity [Min-Max] | kW | 1.40 – 5.40 | ||
| Total Input [Rated] | kW | 1.55 | ||
| Total Input [Min-Max] | kW | 0.30 – 1.98 | ||
| EER | 3.23 | |||
| AEER | 3.22 | |||
| Star Rating |
Hot & Humid |
1.5 | ||
| 3.0 | ||||
| New Star Rating | Mixed | 3.0 | ||
| Cold | 3.0 | |||
|
Running Current
[Rated] |
A | 6.90 | ||
|
SPL |
In [Quiet-Lo-
Mid-Hi-SHi] |
dB(A) | 30 – 43 | |
| Out [PWL] | dB(A) | 52 (65) | ||
|
Air Volume (In) [Quiet-
SHi] |
L/S | 97 – 188 | ||
| Capacity [Rated] | kW | 5.80 | ||
| Capacity [Min-Max] | kW | 1.40 – 7.50 | ||
| Total Input [Rated] | kW | 1.56 | ||
| Total Input [Min-Max] | kW | 0.30 – 2.64 | ||
| COP | 3.72 | |||
| ACOP | 3.71 | |||
| Star Rating |
Hot & Humid |
2.5 | ||
| Heating | 2.5 | |||
| New Star Rating | Mixed | 2.5 | ||
| Cold | 2.0 | |||
|
Running Current
[Rated] |
A | 7.10 | ||
|
SPL |
In [Quiet- SHi] | dB(A) | 30 – 49 | |
| Out [PWL] | dB(A) | 52 (65) | ||
|
Air Volume (In) [Quiet-
SHi] |
L/S | 107 – 243 | ||
|
Piping |
Diameter [Gas/Liquid] | mm | ø9.52/ø6.35 | |
| Max. Length/Height | m | 30/15 | ||
|
Input (Cooling/
Heating) [Rated] |
W | 23/43 | ||
| Indoor Unit | Dimensions [HxWxD] | mm | 299 × 885 × 195 | |
| Weight | kg | 11.5 | ||
|
Outdoor Unit |
Dimensions [HxWxD] | mm | 714 × 800 × 285 | |
| Weight | kg | 40.0 | ||
| Breaker Size | A | 16 | ||
|
Guaranteed
Operating Ra |
nge |
Cooling | °C | |
| [Outdoor] | Heating | °C | ||
| Refrigerant Amount [Pre-Charge] | kg | 0.74 | ||
